Ubiquiti PowerBridge M5 (PBM5), Carrier Class 5GHz MIMO Bridging Solution

Category:

The PowerBridge M5 boasts an impressive array of features and specifications, making it a top-tier choice for long-range wireless bridging applications. Let’s dive into the details:

Processor and Memory

  • Atheros MIPS 24KC processor running at 400MHz
  • 64MB SDRAM and 8MB Flash memory



Networking Interface

  • 1 x 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet interface



Wireless Capabilities

  • Operates in the 5470MHz-5825MHz frequency range
  • Supports both 11a and 11n wireless standards
  • Integrated 2×2 MIMO antenna array with a gain of 24.8-26.5 dBi



Transmit Power and Receive Sensitivity

The PowerBridge M5 delivers impressive performance in both transmit power and receive sensitivity, ensuring reliable and high-speed data transfer. The table below outlines the key specifications:



Modulation Avg. TX Tolerance DataRate Sensitivity Tolerance
1-24Mbps 27 dBm ±2dB -83 dBm ±2dB
36Mbps 25 dBm ±2dB -80 dBm ±2dB
48Mbps 23 dBm ±2dB -77 dBm ±2dB
54Mbps 22 dBm ±2dB -75 dBm ±2dB
MCS0 27 dBm ±2dB -96 dBm ±2dB
MCS1 27 dBm ±2dB -95 dBm ±2dB
MCS2 27 dBm ±2dB -92 dBm ±2dB
MCS3 27 dBm ±2dB -90 dBm ±2dB
MCS4 26 dBm ±2dB -86 dBm ±2dB
MCS5 24 dBm ±2dB -83 dBm ±2dB
MCS6 22 dBm ±2dB -77 dBm ±2dB
MCS7 21 dBm ±2dB -74 dBm ±2dB
MCS8 27 dBm ±2dB -95 dBm ±2dB
MCS9 27 dBm ±2dB -93 dBm ±2dB
MCS10 27 dBm ±2dB -90 dBm ±2dB
MCS11 27 dBm ±2dB -87 dBm ±2dB
MCS12 26 dBm ±2dB -84 dBm ±2dB
MCS13 24 dBm ±2dB -79 dBm ±2dB
MCS14 22 dBm ±2dB -78 dBm ±2dB
MCS15 21 dBm ±2dB -75 dBm ±2dB



Physical and Environmental Specifications

  • Enclosure Size: 445 x 416 x 34mm
  • Weight: 3.82kg
  • Enclosure Material: Outdoor UV-stabilized plastic
  • Mounting Kit: Pole Mounting Kit included
  • Max Power Consumption: 8 Watts
  • Power Supply: 24V, 1A surge protection integrated PoE adapter included
  • Power Method: Passive Power over Ethernet (pairs 4,5+; 7,8 return)
  • Operating Temperature: -30°C to +80°C
  • Operating Humidity: 5 to 95% Condensing
  • Shock and Vibration: ETSI300-019-1.4 compliant



Regulatory and Compliance Information

  • Wireless Approvals: FCC Part 15.247, IC RS210, CE
  • RoHS Compliance: Yes



Antenna Specifications



The PowerBridge M5 features a super-efficient 25dBi MIMO antenna array, providing exceptional performance and coverage. The key antenna specifications are as follows:

  • Frequency Range: 4.9-6.0 GHz
  • Max VSWR: 1.1:1
  • Gain: 24.8-26.5 dBi
  • H-pol Beamwidth: 6 degrees
  • V-pol Beamwidth: 6 degrees
  • Cross-pol Isolation: 28dB minimum



Optimal Applications

The PowerBridge M5 is designed to excel in a wide range of applications, including:

  • Wireless Backhaul: Providing high-speed, reliable connectivity for businesses, communities, and service providers.
  • Point-to-Point Bridging: Enabling seamless data transfer between two remote locations.
  • Wireless Internet Service Providers (WISPs): Delivering fast and stable internet access to underserved areas.
  • Campus Connectivity: Connecting buildings and facilities within a campus or enterprise environment.
  • Event and Temporary Networking: Offering temporary, high-bandwidth connectivity for events, festivals, or disaster relief efforts.
