Name: LNB PLL de banda Ku con referencia interna NJR2839, frecuencia LO: 10.25 GHz, frecuencia IF: 950 a 1,450 MHz
SKU: 11235
Availability: InStock

Parameter	Specifications
RF Input Interface	Waveguide, WR75 (with Groove)
IF Output Interface	– Coaxial Connector, N-type Female (50 Ω)
	– Coaxial Connector, F-type Female (75 Ω)
RF Frequency	– RF Frequency: 11.2 to 11.7 GHz
IF Frequency	– IF Frequency: 950 to 1,450 MHz
LO Frequency	– LO Frequency: 10.25 GHz
Linear Gain	– Linear Gain: 60 dB typ., 55 dB min. @ +25 ℃
Noise Figure (NF)	– Noise Figure (NF): 0.8 dB typ. @ +25 ℃
Input Power Voltage Requirement	– Input Power Voltage Requirement: +24 VDC (+12 to
	+24 VDC)
Current Consumption	– Current Consumption: 250 mA max.
Operating Temperature Range	– Operating Temperature Range: -40 to +60 ℃
Waterproof / Dustproof (IP-code)	– Waterproof / Dustproof (IP-code): IP67
Weight	– Weight: 260 g
Dimensions	– Dimensions (LxWxH): 100.5 x 40 x 40 mm
	(w/o Interfaces & Screws)

Frequency Organization

Parameter	Specifications
RF Frequency	11.2 to 11.7 GHz
IF Frequency	950 to 1,450 MHz
LO Frequency	10.25 GHz

Low Noise Performance

Parameter	Specifications
Noise Figure (NF)	0.8 dB typ. @ +25 ℃

LO Frequency Stability Line-up

Model No.	RF Frequency	Reference Type	LO Frequency Stability	IF Connector
NJR2839H	11.2 to 11.7 GHz	Internal Ref.	+/- 10 ppm	F-type (75Ω)
NJR2839HN	11.2 to 11.7 GHz	Internal Ref.	(+/- 100 kHz typ.)	N-type (50Ω)
NJR2839S	11.2 to 11.7 GHz	Internal Ref.	+/- 3 ppm	F-type (75Ω)
NJR2839SN	11.2 to 11.7 GHz	Internal Ref.	(+/- 30 kHz typ.)	N-type (50Ω)
NJR2839U	11.2 to 11.7 GHz	Internal Ref.	+/- 1 ppm	F-type (75Ω)
NJR2839UN	11.2 to 11.7 GHz	Internal Ref.	(+/- 10 kHz typ.)	N-type (50Ω)

Others

RoHS Compliance
