TC-400-BM-X, BNC-Male (Plug), Straight, Solder, Crimp, Type Connector for LMR 400 Coaxial Cable
Type BNC, male (plug), straight, TC style connector for FBT-400, LMR-400, TCOM-400, and T-RAD-400-FR type cables. The TC-400-BM-X features a solder-pin connector and is a perfect option for stranded center conductors.
In stock (can be backordered)
There are many different types of RG and industry-standard coaxial cables, and BNC connectors can accommodate them all. Quickly connect and disconnect with secure locking is possible with its bayonet-style coupling mechanism.
Just a quarter turn of the coupling nut is all it takes to get them to mate.
| Weight | 0.03798 kg |
|---|---|
| Dimensions | 4.68 × 1.45 × 1.45 cm |
| Brand | Times Microwave System |
| Interface | BNC |
| Gender | male (plug) |
| Orientation | straight |
| PIM Rating | N/A |
| Max Frequency (GHz) | 4 |
| VSWR Freq | <1.35:1 |
| VSWR Frequency (GHz) | 2.5 |
| Inner Contact Attach | Solder |
| Outer Contact Attach | Crimp |
| Body Finish | Alballoy |
| Pin Finish | Gold |
