Name: Cabo Coaxial Commscope Heliax LDF4-50A, cobre corrugado, 1/2 pol., jaqueta PE preta
SKU: 8217
Availability: InStock

Cabo Coaxial Commscope Heliax LDF4-50A, cobre corrugado, 1/2 pol., jaqueta PE preta

Impedance: 50 ohms
Operating Frequency Band: 1 – 8800 MHz
Peak Power: 40 kW
Insulation Resistance: 100,000 MOhms-km
Jacket Spark Test Voltage: 8000 V
Velocity: 88%

Commscope LDF4-50A, HELIAX® Low Density Foam Coaxial Cable, corrugated copper, 1/2 in, black PE jacket (Halogen free jacketing non-fire-retardant)

VSWR/Return Loss for different frequency bands
Material Specifications: Dielectric Material, Jacket Material, Inner Conductor Material, Outer Conductor Material
Mechanical Specifications: Minimum Bend Radius, Tensile Strength, Bending Moment, Flat Plate Crush Strength
Environmental Specifications: Operating Temperature, Storage Temperature, Installation Temperature
Packaging and Weights: Cable weight
Regulatory Compliance/Certifications: CENELEC EN 50575 compliant, ISO 9001:2015, REACH-SVHC Compliant, ROHS Compliant

Frequency (MHz)	Attenuation (dB/100 m)	Attenuation (dB/100 ft)	Average Power (kW)
1.0	0.211	0.064	36.11
1.5	0.259	0.079	29.46
2.0	0.299	0.091	25.5
10.0	0.672	0.205	11.35
20.0	0.954	0.291	7.99
30.0	1.172	0.357	6.51
50.0	1.521	0.463	5.02
85.0	1.995	0.608	3.82
88.0	2.031	0.619	3.76
100.0	2.169	0.661	3.52
108.0	2.256	0.688	3.38
150.0	2.673	0.815	2.85
174.0	2.887	0.88	2.64
200.0	3.103	0.946	2.46
204.0	3.135	0.956	2.43
300.0	3.835	1.169	1.99
400.0	4.462	1.36	1.71
450.0	4.749	1.447	1.61
460.0	4.804	1.464	1.59
500.0	5.021	1.53	1.52
512.0	5.085	1.55	1.5
600.0	5.533	1.686	1.38
700.0	6.009	1.831	1.27
800.0	6.456	1.968	1.18
824.0	6.56	1.999	1.16
894.0	6.855	2.089	1.11
960.0	7.124	2.171	1.07
1000.0	7.284	2.22	1.05
1218.0	8.11	2.472	0.94
1250.0	8.226	2.507	0.93
1500.0	9.093	2.771	0.84
1700.0	9.744	2.97	0.78
1794.0	10.039	3.06	0.76
1800.0	10.058	3.066	0.76
2000.0	10.666	3.251	0.72
2100.0	10.961	3.341	0.7
2200.0	11.251	3.429	0.68
2300.0	11.535	3.516	0.66
2500.0	12.09	3.685	0.63
2700.0	12.627	3.849	0.6
3000.0	13.407	4.086	0.57
3400.0	14.401	4.389	0.53
3600.0	14.882	4.536	0.51
3700.0	15.118	4.608	0.5
3800.0	15.353	4.679	0.5
3900.0	15.585	4.75	0.49
4000.0	15.815	4.82	0.48
4100.0	16.042	4.889	0.48
4200.0	16.268	4.958	0.47
4300.0	16.492	5.027	0.46
4400.0	16.714	5.094	0.46
4500.0	16.934	5.161	0.45
4600.0	17.153	5.228	0.44
4700.0	17.37	5.294	0.44
4800.0	17.585	5.36	0.43
4900.0	17.798	5.425	0.43
5000.0	18.01	5.489	0.42
6000.0	20.055	6.113	0.38
8000.0	23.826	7.262	0.32
8800.0	25.244	7.694	0.3

Frequency Band (MHz)	VSWR
680–800	1.13
800–960	1.13
1700–2200	1.13
2300–2700	1.13

Material Specifications:

Material	Specification
Dielectric Material	Foam PE
Jacket Material	PE
Inner Conductor Material	Copper-clad aluminum wire
Outer Conductor Material	Corrugated copper

Mechanical Specifications:

Specification	Value
Minimum Bend Radius, multiple Bends	127 mm
Minimum Bend Radius, single Bend	50.8 mm
Number of Bends, minimum	15
Number of Bends, typical	50
Tensile Strength	113 kg
Bending Moment	3.8 N-m
Flat Plate Crush Strength	2 kg/mm

Environmental Specifications:

Specification	Value
Installation temperature	-40 °C to +60 °C (-40 °F to +140 °F)
Operating Temperature	-55 °C to +85 °C (-67 °F to +185 °F)
Storage Temperature	-70 °C to +85 °C (-94 °F to +185 °F)
Attenuation, Ambient Temperature	68 °F
Average Power, Ambient Temperature	104 °F
Average Power, Inner Conductor Temp	212 °F
