Рация Entel DX446E без лицензии, профессионального уровня
- Entry & Advanced model
- DMR Digital & analogue modes
- Submersible IP68
- Loudest In Class Audi
В наличии (может быть предзаказано)
The DX400 Series radios are designed to be ultra-compact, lightweight, and dual-mode, supporting both Analogue and Digital modes. These rugged and fully-submersible radios utilize advanced DMR digital technology along with Entel audio tailoring technology, delivering optimal range and clarity for communication.
The DX400 Series offers both Tier 1 and Tier 2 options, featuring models with and without displays.
Tier 1 is designed for commercial and leisure applications with direct mode operation, prohibiting the use of repeaters. It is fully approved for use in Europe, and no license is required for operation.
Tier 2 is suitable for small to medium-sized licensed systems. Radios in Tier 2 can operate in direct mode or, when an extended range is needed, can be used with a repeater. Tier 2 repeaters can also be networked to further expand the coverage area.
| tems | Parameters |
|---|---|
| Channel Capacity | DX4x2/DX446E – 16 channels, DX4x5/DX446L – 99 channels / 8 zones |
| Channel Spacing | 12.5KHz & 25KHz |
| Vocoder | AMBE+2 |
| Operating Voltage | 7.6V |
| Battery | CNB450E 2200mAh Lithium-ion |
| Weight | – Display model: 267g |
| – Non-display model: 257g | |
| Overall Dimensions (HxWxD) | 97mm x 59.5mm x 37mm (with CNB450E) |
| Battery Endurance (5/5/90) | – Analogue mode: 14 hours |
| – Digital mode: 21 hours | |
| Frequency Stability | ±0.5ppm |
| Antenna Impedance | 50 ohm |
| Operating Temperature | -20 to +55°C |
| Dust and Liquid Intrusion | IP68 (2 metres for 4 hours) |
| Drop Test | Compliant with MIL-STD810 C/D/E/F/G |
| Vibration and Shock | Approvals: EN 300 086 v2.1.2, EN 300 113 v2.2.1, EN 301 489-1 v2.2.3, EN 301 489-5 v2.2.1, EN 62368-1:2020 + A11:2020, EN 50566:2017, EN 62311:2008 & EN 62209 – 2:2010, EN 300 296 v2.1.1 |
| Air Interface | DMR Compliant with ETSI TS 102 361-1-2-3 |
Transmitter:
| Items | Parameters |
|---|---|
| Power Output VHF (HI/LOW) | 5W/1W |
| Power Output UHF (HI/LOW) | 4W/1W |
| Power Output PMR446/DMR446 | 0.5W |
| Audio Distortion | <5% |
| Unwanted Emission | -57dBm up to 1GHz, -47dBm from 1GHz to 4GHz |
| Adjacent Channel Power | -60dBc |
Receiver:
| Items | Parameters |
|---|---|
| Digital Sensitivity | Typically -121dBm (0.2uV) for 5% BER |
| Analogue Sensitivity | Typically -121dBm (0.2uV) for 12dB Sinad |
| Rated Audio Output | 2 watts |
| Intermodulation Response | >65dB |
| Adjacent Channel Selectivity | >70dB / >60dB |
| Spurious Rejection | >70dB |
| Audio Response | 300Hz to 3KHz -6dB/Octave |
| Audio Distortion | <5% |
| Conducted Spurious Emissions | -57dBm up to 1GHz, -47dBm from 1GHz to 4GHz |
Note: The information provided is based on the available specifications and may be subject to change due to potential updates or revisions in the product design.
