Name: Belden 1841A Çift RG6 Kablo, 18 AWG BCCS, Folyo + Örgü, CM
SKU: 6911
Availability: InStock

Introducing premium Series 6 Dual Coaxial Cable, meticulously designed for superior performance. This high-quality cable boasts an 18 AWG solid .040″ bare copper-covered steel conductor, ensuring robust connectivity. Its gas-injected foam polyethylene insulation guarantees optimal signal integrity, while the innovative Duobond® II technology enhances durability.

Equipped with a reliable aluminum braid shield providing 60% coverage, this cable offers excellent interference protection. The exterior is encased in a durable PVC jacket, ensuring long-lasting use. Elevate your audio and video experience with our Series 6 Dual Coaxial Cable – the perfect choice for reliable and high-performance connections. Upgrade your connectivity today!

Designed to withstand diverse environmental conditions, our Series 6 Dual Coaxial Cable operates flawlessly within a broad temperature range from -40°C to +80°C. With a non-UL temperature rating of 80°C, this cable ensures reliability and performance even in demanding scenarios.

Crafted with precision, the cable weighs 83.339 Kg/Km in bulk, offering a balance of durability and flexibility. It can withstand a maximum recommended pulling tension of 1120.946 N, ensuring ease of installation without compromising its structural integrity.

The cable’s design incorporates a minimal bend radius of 76.200 mm along the minor axis, allowing for efficient and versatile installations in various settings. Trust in the resilience and adaptability of our Series 6 Dual Coaxial Cable to meet your connectivity needs across a wide

Physical Characteristics (Overall):

Conductor	AWG:	# Coax AWG Stranding Conductor Material Dia. (mm)
	2	18 Solid BCCS – Bare Copper Covered Steel 1.016
Total Number of Conductors: 2

Insulation	Insulation Material:	Insulation Material Dia. (mm)
	Gas-injected FPE – Foam Polyethylene	4.572

Outer Shield	Outer Shield Material:	Layer # Outer Shield Trade Name Type Outer Shield Material Coverage (%)
	1 Bonded Duofoil® Tape Bonded Aluminum Foil-Polyester Tape-Aluminum Foil	100
	2 Braid	AL – Aluminum

Outer Jacket	Outer Jacket Material:	Outer Jacket Material
	PVC – Polyvinyl Chloride

Overall Cable	Overall Nominal Diameter:
	6.934 x 15.113 mm

HIGH FREQUENCY CHARACTERISTICS:

Frequency [MHz]	Nom. Insertion Loss
5	0.5 dB/100ft
55	1.4 dB/100ft
211	2.6 dB/100ft
500	4.1 dB/100ft
750	5.1 dB/100ft
862	5.5 dB/100ft
1000	6 dB/100ft
1450	7.8 dB/100ft
1800	8.6 dB/100ft
2250	9.8 dB/100ft
3000	11.3 dB/100ft

MECHANICAL CHARACTERISTICS:

Bulk Cable Weight: 56 lbs/1000ft
Max. Pull Tension: 252 lbs
Min. Bend Radius/Minor Axis: 3 in

STANDARDS:

NEC/(UL) Compliance: CATV, CM
CEC/C(UL) Compliance: CM
RG Type: 6
Series Type: 6

APPLICABLE ENVIRONMENTAL AND OTHER PROGRAMS:

Temperature Range:
- Non-UL Temp Rating: 80°C
- Operating Temperature Range: -40°C to +80°C
