Belden GOCN812 Outdoor OFC CLT (jelly filled): GLASS YARNS + CST + PE with 1 Tube of Ø3.3mm 12f SM OS2 G.652.D & G.657.A1

Construction Type: Central Loose Tube
Environmental Space: Outdoor
Rodent Protection: Corrugated Steel Tape armor
Water Blocking: Waterblocking Glass Yarns + Tape

Description
Additional information

The Belden GOCN812 is an advanced outdoor optical fiber cable designed for demanding environments. It features a Central Loose Tube construction with enhanced rodent protection, making it ideal for various outdoor applications, including industrial and telecom networks.

Applications

The GOCN812 cable is suitable for:

Structured data wiring systems
Industrial backbone networks
Campus backbone installations
Building backbone (riser) cabling
Horizontal cabling for outdoor use
Direct burial in trenches and ducts

Technical Specifications

Fiber Cable Construction

Specification	Details
Fiber Type	OS2 G.652D & G.657A1
Fiber Count	12
Subunit Color	Natural
Water Tight	Yes
Bulk Cable Weight	81 kg/km

Subunit Specifications

Specification	Details
Number of Active Subunits	1
Subunit Diameter	3.3 mm
Subunit Waterblocking	Gel Filled

Jacket Specifications

Specification	Details
Number of Jackets	Single Jacket
Type of Armor	Corrugated Steel Tape
Outer Jacket Material	PE – Polyethylene
Outer Jacket Color	Black
Nominal Diameter	9.0 mm
Ripcord	Yes

Optical Characteristics

The GOCN812 cable offers excellent optical performance, which is crucial for high-speed data transmission.

Wavelength (nm)	Max. Attenuation (dB/km)
1310	0.39
1550	0.24
1625	0.29

Mechanical Characteristics

The mechanical integrity of the GOCN812 cable ensures durability and reliability under various conditions.

Test Description	Requirement/Value	Standard
Min. Bend Radius (Installation)	180 mm	IEC 60794-1-21-E6
Min. Bend Radius (Operation)	180 mm	IEC 60794-1-21-E11
Max. Tensile Strength (Installation)	2400 N (540 lbf)	IEC 60794-1-21-E1
Max. Tensile Strength (Operation)	800 N (180 lbf)	IEC 60794-1-21-E1
Max. Crush Resistance (Installation)	22 kN/m	IEC 60794-1-21-E3
Max. Crush Resistance (Operation)	11 kN/m	IEC 60794-1-21-E3

Temperature Ranges

Operating Temperature Range: -30 °C to +70 °C
Installation Temperature Range: -5 °C to +50 °C
Storage Temperature Range: -30 °C to +70 °C

Compliance and Standards

The GOCN812 cable meets various industry standards, ensuring its reliability and safety:

UL Rating/Flame Test: Non-UL Rated
REACH Compliance: Yes
ISO/IEC Compliance: IEC 60794
EU Directive 2011/65/EU (RoHS 2): Compliant
UV/Sunlight Protection: Yes

Related Part Numbers

The GOCN812 is available in different lengths and colors:

Item #	Color	Put-Up Type	Length	EAN
GOCN812.002100	Black	Reel	2,100 m	8719605077356
GOCN812.004100	Black	Reel	4,100 m	8719605077363

Conclusion

The Belden GOCN812 is a versatile and robust outdoor optical fiber cable that meets the needs of a wide range of applications. Its superior construction, excellent optical characteristics, and compliance with industry standards make it an ideal choice for outdoor data transmission in various environments.
