40W iBUC 2g GaN Ka-Band 29.500 to 30.000 – Terrasat
MPN# IBR295300-0NA041WW-0000
Equipped with:
- AGC/ALC
- Internal diagnostics
- FSK M&C capable
- TCP/IP via RJ45 connector with embedded web pages and SNMP
- RS485, RS232 alarm, handheld ports
- Multifunction LED indicator
Installation Kit, w/Mounting bracket, ‘saddle’ for IBUC2g. With bolts and plate for attachment to 3 x 3 boom support
M&C RJ45 mating connector, shielded
Internal 10MHz reference Option:
Including the internal reference changes the part number. The digit after the frequency designator changes from a “0” to a “2”. Example: IBR295300-0NA041WW-0000 becomes IBR295300-2NA041WW-0000.
The IBUC Advantage
All IBIJCs are equipped with cutting-edge intelligent technology:
- Highest quality & exacting performance guaranteed through individual unit testing over temperature
- Superior linearity for maximum useable output power
- Amplifier overdrive protection
- User-selectable AGC/ALC for optimal performance & compatibility With modem adaptive coding
- New high capacity microprocessor & extended M&C functions
- Weatherized RJ45 Ethernet interface for simplified connection
ULTIMATE MANAGEMENT & CONTROL
- Local Web Interface & NMS-Friendly SNMP
- user Configurable Thresholds & Alarms a
- Upgraded Event Log with 1.000 Sensor Readings
- D Performance Trend Analysis Tools & Statistical logs
- Embedded Web Pages for Universal Web Browser Access
| Parameter | Specification |
|---|---|
| Frequency Range | |
| RF | 29.0 to 30.0 GHz |
| IF | 1.0 to 2.0 GHz (Standard Version1) |
| 1.0 to 1.5 GHz (WGS Version2) | |
| Input | |
| VSWR/Impedance | 1.5:1 / 50 Ohm |
| Input Connector Type | N Female (50 Ohm) |
| Input Connector Options | Type F (75 Ohm), TNC (50 Ohm) |
| Input Power Detector | Standard Version1: -55 to -20 dBm |
| WGS Version2: -35 to 0 dBm | |
| Gain | |
| Small Signal Gain (L-band to RF) | |
| with attenuator set to 0 dB | Standard Version1 |
| 5W | 68 dB min |
| 10W | 71 dB min |
| 16W | 73 dB min |
| 20W | 74 dB min |
| 25W | 75 dB min |
| 40W | 77 dB min |
| 50W | 78 dB min |
| Note: Terrasats Standard Version has higher gain to reduce the need for line amplifiers in long cable runs (IFL). | |
| WGS Compatible Versions have lower gain allowing operations to drive the IF signal up to 0 dBm. | |
| Attenuator | 30 dB variable in 0.1 dB steps |
| Gain Flatness | |
| Full Band | 4 dB p-p max |
| 36 MHz | 1.5 dB p-p max |
| Gain Variation Over Temperature | |
| Open Loop | 4 dB p-p max |
| With AGC | 1 dB p-p max |
| RF Output | |
| Interface | WR28 UG Cover with Groove |
| VSWR | 1.3:1 max |
| Output Power | |
| Psat (typ) | Varies with input power |
| PLin (min) | Varies with input power |
| 19 dB min of NPR | Varies with input power |
| at: | |
| 5W | +37 dBm |
| 10W | +40 dBm |
| 16W | +42 dBm |
| 20W | +43 dBm |
| 25W | +44 dBm |
| 40W | +46 dBm |
| 50W | +47 dBm |
| Note: PLin is the maximum linear power as defined by MIL STD 188-164C. Two-tone measured at 5 MHz and 150 MHz spacing. | |
| Level stability with ALC ± 0.5 dB. Output power detector range: Rated power to -20 dB. Power reading accuracy ± 1.0 dB max. | |
| Spurious @PLin | In Band: -60 dBc |
| Out of Band: -60 dBc | |
| Complies with EN 301 428/430 & MIL-STD 188-164C | |
| AM/PM Conversion | <2 Deg/dB @ PLinear |
| Output Noise Power Density | Tx < -74 dBm/Hz |
