MikroTik CCR2004-16G-2S+: A Powerful and Affordable Router
The MikroTik CCR2004-16G-2S+ is a feature-rich and high-performance router that offers an impressive set of capabilities for small to medium-sized businesses. Packed with advanced hardware and software features, this model stands out as a compelling choice in the CCR series lineup.
Specifications
Specification | Details |
---|---|
Product Code | CCR2004-16G-2S+ |
Architecture | ARM 64-bit |
CPU | AL32400 |
CPU Core Count | 4 |
CPU Nominal Frequency | 1700 MHz |
Switch Chip Model | 88E6191X |
Dimensions | 443 x 210 x 44 mm |
RouterOS License | 6 |
Operating System | RouterOS v7 |
RAM Size | 4 GB |
Storage Size | 128 MB |
Storage Type | NAND |
MTBF | Approximately 200,000 hours at 25°C |
Tested Ambient Temperature | -20°C to 60°C |
IPsec Hardware Acceleration | Yes |
Suggested Price | $465.00 |
Powering
Detail | Specification |
---|---|
Number of AC Inputs | 2 |
AC Input Range | 100-240 V |
Frequency (Hz) | 47-63 |
Max Power Consumption | 48 W |
Max Power Consumption without Attachments | 35 W |
Cooling Type | 2 fans |
Ethernet
Detail | Specification |
---|---|
10/100/1000 Ethernet Ports | 16 |
Fiber
Detail | Specification |
---|---|
SFP+ Ports | 2 |
Peripherals
Detail | Specification |
---|---|
Serial Console Port | RJ45 |
Other Features
- CPU temperature monitor
- PCB temperature monitor
- Voltage monitor
Certifications and Approvals
- CE
- EAC
- RoHS
Included Parts
- Rack ears
- IEC cords (2)
- K-57 kit
Performance Highlights
The MikroTik CCR2004-16G-2S+ is a powerhouse in terms of performance, delivering exceptional results in various test scenarios:
Ethernet Test Results
Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
---|---|---|---|---|---|---|---|
kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
Bridging | none (fast path) | 2925.93 | 5532.16 | 775.12 | 750.89 | 776.75 | 318.5 |
25 bridge filter rules | 1396.61 | 6960.31 | 410.75 | 778.21 | 375.27 | 48.1 | |
Routing | none (fast path) | 2925.93 | 5532.16 | 6947.6 | 4643.98 | 2860.64 | 493.8 |
25 simple queues | 1186.31 | 4406.19 | 933.79 | 917.61 | 1196.96 | 651.1 | |
25 ip filter rules | 722.28 | 8770.4 | 1114.74 | 565.8 | 724.4 | 394.1 |
IPsec Test Results
Mode | Configuration | 1400 byte | 512 byte | 64 byte | |||
---|---|---|---|---|---|---|---|
kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
Single Tunnel | AES-128-CBC + SHA1 | 202.0 | 273.6 | 204.1 | 836 | 202.2 | 103.5 |
256 Tunnels | AES-128-CBC + SHA1 | 232.4 | 2602.9 | 230.5 | 944.1 | 222.2 | 113.8 |
256 Tunnels | AES-128-CBC + SHA256 | 232.4 | 2602.9 | 230.5 | 944.1 | 222.2 | 113.8 |
256 Tunnels | AES-256-CBC + SHA1 | 232.3 | 2601.8 | 227.3 | 931 | 238.1 | 121.9 |
256 Tunnels | AES-256-CBC + SHA256 | 232.3 | 2601.8 | 227.3 | 931 | 238.1 | 121.9 |
All tests were conducted using Xena Networks specialized test equipment (XenaBay), following the RFC2544 (Xena2544) standard. The results demonstrate the device’s maximum performance capabilities under the specified hardware and software configurations.
Key Features and Benefits
- Powerful CPU: The CCR2004-16G-2S+ is equipped with the Annapurna Labs Alpine v2 CPU, featuring 4 x 64-bit ARMv8-A Cortex-A57 cores running at 1.7 GHz. This CPU delivers exceptional single-core performance, outperforming previous CCR models in heavy, per-connection-based operations like queuing.
- Efficient Performance: The router boasts the best single-core performance per watt and the best overall performance per watt among all CCR devices, making it an energy-efficient and cost-effective solution.
- Extensive Connectivity: With 16 Gigabit Ethernet ports and 2 10G SFP+ cages, the CCR2004-16G-2S+ provides ample wired connectivity options for small to medium-sized businesses, allowing for flexible network configurations.
- Redundancy and Cooling: The router features built-in dual redundant power supplies and active cooling with two fans, ensuring reliable and stable operation.
- Affordability: Despite its impressive capabilities, the CCR2004-16G-2S+ is priced competitively, making it an attractive choice in the market.
Ideal Use Cases
The CCR2004-16G-2S+ is well-suited for a variety of use cases, including:
- Small to Medium-Sized Business Networks: The router’s 16 Gigabit Ethernet ports and 2 10G SFP+ cages make it an excellent choice for internal network connectivity, while the SFP+ ports can be used for uplink and downlink connections.
- Edge Routing and Firewalling: The router’s powerful CPU and advanced software features enable it to handle demanding routing and firewall tasks, making it a suitable choice for edge network deployments.
- High-Performance VPN Connectivity: The CCR2004-16G-2S+ offers IPsec hardware acceleration, allowing it to efficiently handle VPN traffic with minimal impact on overall system performance.
- Network Automation and Monitoring: The router’s rich set of features and capabilities, combined with the flexibility of the RouterOS operating system, make it a powerful platform for network automation and monitoring tasks.
The MikroTik CCR2004-16G-2S+ is a feature-rich and high-performance router that delivers impressive capabilities in a compact and affordable package. Its powerful CPU, extensive connectivity options, redundancy features, and energy-efficient design make it a compelling choice for small to medium-sized businesses looking to optimize their network infrastructure. With its robust performance and versatile feature set, the CCR2004-16G-2S+ is poised to elevate your office network to new heights.
