Agilis Compact 16W/20W/25W Ku Band BUC (Block-Up Converter)
- Engineered for direct mounting on the feedhorn, this compact and rugged BUC (Block Upconverter) is perfectly suited for Satellite-On-The-Move (SOTM), fixed ground stations, and maritime communication systems. Its advanced thermal management system ensures superior power efficiency and reliable performance, even in the most demanding outdoor environments.
- Built for long-term durability and minimal maintenance, this BUC offers an innovative design that maximizes cooling efficiency without compromising on output power. Installation is straightforward, with built-in support for 1+1 redundancy configurations—making it ideal for mission-critical and always-on operations.
-
Direct Feedhorn Mounting: Reduces system complexity and improves signal integrity.
-
Optimized for Harsh Conditions: Robust design ensures consistent performance in extreme weather.
-
Thermal Efficiency: Minimizes energy consumption while maintaining peak performance.
-
Redundancy-Ready: Supports 1+1 configurations for increased uptime and system reliability.
-
Ideal for SOTM, Fixed, and Maritime Use: Versatile design meets a wide range of satellite communication needs.
Technical Specifications – BUC Series (ALB129)
RF Specifications
| Category | Details |
|---|---|
| Transmit Frequency | Standard: 14.00 – 14.50 GHz Extended: 13.75 – 14.50 GHz |
| IF Input Frequency | Standard: 950 – 1450 MHz Extended: 950 – 1700 MHz |
| Local Oscillator (LO) | Standard: 13.05 GHz Extended: 12.80 GHz |
Output Power
| Model (ALB129) | P1dB Output Power | PLinear Power |
|---|---|---|
| 16W | 42.0 dBm (16W) | 39.0 dBm (8W) |
| 20W | 43.0 dBm (20W) | 40.0 dBm (10W) |
| 25W | 44.0 dBm (25W) | 41.0 dBm (12.5W) |
Gain and Linearity
| Parameter | Specification |
|---|---|
| Small Signal Gain | 68 dB (min) |
| Gain Flatness | ±2 dB across full band ±1 dB over 40 MHz |
| Gain Variation (Temp.) | ±2 dB over operating temperature |
| Intermodulation | -25 dBc max @ PLinear |
| Spurious | Compliant with EN 301 428 |
| Phase Noise | -93 dBc/Hz max @ 100 kHz offset -83 dBc/Hz max @ 10 kHz -73 dBc/Hz max @ 1 kHz |
| VSWR | 1.5:1 max @ input 1.25:1 max @ output (with optional isolator) |
Noise Power Density
| Band | Max Noise Density |
|---|---|
| Tx Band | -70 dBW/4kHz |
| Rx Band | -142 dBW/4kHz |
Power Specifications
| Parameter | Specification |
|---|---|
| Prime Power | 38 to 60 VDC (DC Model) 90 to 264 VAC, 47–63 Hz (AC Model) |
| Power Consumption | 200 VA max @ 16W 220 VA max @ 20W 240 VA max @ 25W |
Interfaces
| Function | Connector Type |
|---|---|
| IF Input | N-Type Female, 50Ω F-Type Female, 75Ω (optional) |
| RF Output | WR75, Square Grooved |
Reference Signal Requirements
| Parameter | Specification |
|---|---|
| Reference Frequency | 10 MHz |
| Reference Source | External (standard) Internal (optional) |
| External Ref Power Level | -5 dBm to +5 dBm |
| External Ref Phase Noise | -160 dBc/Hz max @ 100 kHz -155 dBc/Hz max @ 10 kHz -150 dBc/Hz max @ 1 kHz |
Monitor & Control Features
| Function | Details |
|---|---|
| Temperature Monitoring | Real-time BUC temperature monitoring |
| Status Alarms | LO Unlock and system alarm via LED indicator |
| Power Detection | RF forward power detection |
| Gain Control | 0 to 20 dB adjustable in 0.5 dB steps |
| Output Control | RF Output On/Off (Mute) |
| Communication Interfaces | Serial RS232 / RS485, Ethernet (supports SNMP & HTTP protocols) |
| Redundancy Support | Redundancy-ready (via external controller unit) |
Environmental Specifications
| Parameter | Specification |
|---|---|
| Operating Temperature | -40°C to +60°C |
| Relative Humidity | Up to 100% |
| Ingress Protection | IP65 rated (weatherproof) |
Mechanical Specifications
| Model Type | Dimensions (L x W x H) | Weight |
|---|---|---|
| 16W / 20W (DC Model) | 200 x 130 x 113 mm 7.87” x 5.12” x 4.43” |
2.8 kg / 6.2 lbs |
| 25W (DC Model) | 200 x 130 x 130 mm 7.87” x 5.12” x 5.12” |
3.3 kg / 7.3 lbs |
| All Power Ratings (AC Model) | 200 x 130 x 203 mm 7.87” x 5.12” x 7.99” |
4.7 kg / 10.3 lbs |
